Foton Auman 8×4 dump truck 80t LHD aggregate delivery Cummins Engine
Foton Auman 8×4 dump truck 80t LHD aggregate delivery Cummins Engine
Foton Auman 8×4 dump truck 80t LHD aggregate delivery Cummins Engine
Foton Auman 8×4 dump truck 80t LHD aggregate delivery Cummins Engine

Foton Auman 8×4 dump truck 80t LHD aggregate delivery Cummins Engine

Market Price: from $56624 (NO include VAT)

Series: Auman EST

Usage scenario: mining haulage/quarry transport/construction earthmoving/aggregate delivery

Max Power: 400

Drive Type: 8X4

Wheelbase(mm): 1800+3300+1400

Engine/Battery: Foton Cummins ISG 400

Transmission: Sinotruk HW23712 Iron (Q)

truck inspection
factory visiting
Category Details
Serial No. 262
Business Heavy Truck
Function Dump Truck
Sub-brand GTL-E
Tonnage 80T
Approved Model BJ3319DPPKC-3
Drive Type 8×4
Wheelbase 1800+3300+1400 mm
Overall Vehicle (Chassis) Dimensions 9600/9900×2495×3580 mm
Upper Structure Configuration Rectangular / U-shaped bucket, 6800×2300×1500 mm, Q345 steel plate, bottom 8 mm side 6 mm, HYVA cylinder
GCW 80000 kg
Body Width 2490 mm
Roof Height Flat Roof
Left/Right Hand Drive Left Hand Drive
Seating Capacity 2
Fuel Type Diesel
Engine ISG 400
Engine Manufacturer Cummins
Displacement 11800 cc
Emission Standard No Emission
Power / RPM (kW / PS) 294 kW / 400 PS @ 1900 rpm
Engine Torque (Nm / rpm) 2100 Nm @ 1000 rpm
Transmission Model HW23712 Iron (Q)
Transmission Manufacturer Sinotruk
Front Axle Capacity 9T
Middle/Rear Axle Capacity 16T
Drive Axle Ratio 5.26
Brake Type Air Brake
Braking Mechanism Front Drum Rear Drum
Brake Control System ABS
Tire Model 13R22.5 18PR Mixed / Drive
Number of Tires 13
Steering Gear AM105L-S
Fuel Tank Capacity 350L Aluminum Alloy
Suspension Type Leaf Spring
Leaf Spring Count 11, 11, 14
Frame Cross-Section (mm) 225/320×90×(8+7)
Standard Air Conditioning Automatic Air Conditioning
Standard Infotainment System (incl. radar) MP3 + Radio + USB + No Radar
Standard Body Assembly (Seats, Doors/Windows, Mirrors) Power Windows + Central Locking + Remote Lock + Five-in-One Lock + Airbag Seat (standard) + Manual Mirrors
Fifth Wheel None
Optional Bumper Small bumper
Satellite Positioning Device Optional
Battery (Ah) 165
Wheel Cover Optional None
Air Filter Type Optional Desert air filter

The Auman GTL-E 80-ton 8×4 dump truck is a true heavy-duty champion engineered for the most demanding mining and construction sites. Powered by the Cummins ISG 400 engine delivering 400 PS and massive 2100 Nm of torque, combined with robust transmission and 8×4 drive configuration, this dump truck provides unmatched traction and stability even when fully loaded with 80 tons.

Its large 6800×2300×1500 mm heavy-duty bucket (bottom 8 mm, side 6 mm, Q345 steel) with HYVA cylinder ensures fast and reliable unloading. Reinforced multi-leaf suspension, 13 heavy-duty tires and strong frame make it perfect for intensive mining haulage, quarry transport, large-scale construction earthmoving and high-volume aggregate delivery. The comfortable cab with automatic air conditioning, power windows and airbag seat keeps operators fresh during long working days of mining haulage and quarry transport.

Choose this Auman dump truck to achieve faster cycle times, lower cost per ton, higher daily output and superior reliability in construction earthmoving and aggregate delivery operations every single day.
