Home > Products > Special truck > Foton AUV 12M Diesel tour coach tourist bus intercity bus long-distance>
Market Price: from $88,800
Series: Foton AUV
Usage scenario: intercity bus/long-distance bus/tour coach/tourist bus/tourist tram
Max Power: 330
Drive Type: 4X2
Wheelbase(mm): 6500
Engine/Battery: YCK08330-50
Transmission: Fast 6DS180T MT
| BJ6122 Diesel Bus Configuration Table | ||||
| Basic specification | Model and body structure | Semi-Monocoque ,Flat floor | Curb weight(T) | 13.5 |
| Product model | BJ6122 | Max. gross weight(T) | 18.5 | |
| Driver location | Right-hand drive | Fuel consumption under limit condition (L/100Km) | ≤25 | |
| Exterior dimensions（mm） | 12500×2550×3790 | Approach/Departure angle(°) | 8.5/9 | |
| Wheelbase ( mm ) | 6500 | Min. ground clearance （mm） | 165 | |
| Inner height(mm) | ≥1900 | Min. turning radius（m） | ≤13 | |
| Luggage compartment（m³） | 9.6 | Max. gradeability(%） | ≥25% | |
| Braking distance(V=30Km/h at full load)(m) | ≤10 | Inner noise（50Km/H at constant speed） | ≤72 dB(A) | |
| Engine Specification | ||||
| Engine | Model/Brand | YCK08330-50 | Type | In-line,six-cylinder, water cooling, four-stroke, DI, intercooling, 18 valve,diesel engine. |
| Rated power KW(PS)/rpm | 330HP/2200rpm | Displacement /L | 7.7L | |
| Torque | 1700Nm/1200rpm | Emission | Euro 5 | |
| Chassis Specification | ||||
| Chassis | Transmission | Fast 6DS180T MT | ||
| Retarder | Hydraulic retarder | |||
| Transmission control | with | |||
| Air assist system | with | |||
| Front axle | 6.5T Front axle | |||
| Rear axle | 13T Rear axle | |||
| Clutch | SACHS φ430clutch | |||
| Steering | Integral power steering | |||
| Braking | Front & rear Disc brake | |||
| Suspension structure | Koman air suspension with 6 airbags(F2 /R4) | |||
| Frame | Semi-monocoque | |||
| ABS | WABCO ABS | |||
| Fuel tank capacity | 300L*2 | |||
| Automatic clearance adjuster | With | |||
| Tyre ＆ rim | 295/80R22.5 with one spare tire | |||
| Alloy wheel rim | ||||
| Body Specification | ||||
| Body frame | Semi- monocoque body structure | |||
| Front passenger door | Auto Door (Pneumatic) Outward Swing Door, remote control | |||
| Middle passenger door | N/A | |||
| Emergency door | Emergency door at right side | |||
| Rear windshield | Tempered glass,F green | |||
| Front windshield | Laminating glass, colorless ,in two pieces design | |||
| Side window | All Closed, Tinted,Tail window sliding. | |||
| Side window glass color | Light Gray | |||
| Driver Window | Single layer inner sliding, colorless | |||
| Exterior rear-view mirror | Electric rearview mirror (with defrost),Double rabbit ear style | |||
| Body | Launder | With |
| Luggage door | Automatic luggage compartment door | |
| Intake location | Side | |
| Luggage rack | Luggage rack on both sides | |
| Cold wind pipe | Molding cold wind pipe | |
| Air outlet | Air outlet with reading lamp | |
| Top windshield | Two roof hatch,With ventilation | |
| Floor leather | Anti-wear floor leather | |
| Floor | 15mm bamboo floor | |
| Passenger seat | 49 seats | |
| Driver seat | Adjustable airbag driver seat | |
| Driver seat inclosure | Three points safety belt | |
| Guide seat | High back guide seat with three point safety belt | |
| Safety board | Soft foam guardrail | |
| Side curtain | With | |
| Driver side curtain | Fabric driver side curtain | |
| Sun-visor | Manual sun-visor | |
| Battery | 24 V DC/195 Ah x 2，Maintenance Free | |
| Light and signal system | LED Strip lamp | |
| Exterior light bar | ||
| Interior air lamp（Davit lamp） | ||
| Electronic clock | With thermometer | |
| Visual and audio system | Front 24" fixed and middle lifting19" TV | |
| Vehicle Mounted System | 4 camera,hard disk memory,500GB | |
| Dynamo | Double 150A dynamotor | |
| A/C | Songz 34000Kcal/hl （High temperator type) | |
| Bock Compressor | ||
| Defroster | With | |
| Safety hammers | Anti-theft alarm safety hammers (6 pieces) | |
| Others | Driver Sleeping compartment | |
| Sleeping compartment | ||
| Central lubrication system | ||
| TPMS(Tire Pressure Monitor System) | ||
| Refrigerator | ||
| LED step light | ||
| Daytime running lights | ||
| Engine compartment automatic fire extinguisher | ||
| Engine compartment temperature alarm device | ||
| FOB TianJin port 100%L/C at sight or TT in USD | US$ 78,600.00 | |
| Ocean freight by RO-RO ship for Colombo | US$ 12,669.00 | |
| Ocean freight by general bulk carrier ship for Colombo | US$ 7,712.00 | |
| Warranty: Above quotation includes warranty: 180,000km or 24 months after receipt,whichever comes first . | ||
| This vehicle is sold in the following countries: Sri Lanka, Bhutan, Maldives, Bangladesh, Nepal, Pakistan, and India. | ||
Engineered for excellence, the BJ6122 Diesel Bus redefines comfort and reliability for modern passenger transportation. Whether you're planning intercity bus routes, organizing long-distance bus tours, or curating premium tour coach experiences, this vehicle delivers unmatched performance and sophistication.
Equipped with a robust YCK08330-50 diesel engine (330HP/2200rpm, 1700Nm torque), the BJ6122 ensures seamless power for tourist bus operations across diverse terrains. Its Euro 5 emission compliance and fuel efficiency of ≤25L/100km under limit conditions make it eco-friendly and cost-effective for intercity bus fleets.
Step into a "ground-level first-class cabin" with 49 ergonomic seats featuring dual-density sponge cushions and aircraft-inspired business class design. The 19mm bamboo flooring, LED ambient lighting, and 24-inch front TV ensure passengers on your tour coach or tourist bus enjoy premium comfort. The spacious 9.6m³ luggage compartment and 34,000Kcal/h air conditioning system cater to long-haul journeys with ease.
Advanced safety features include WABCO ABS, hydraulic retarder, and 6 airbags suspension for a smooth ride. The TPMS tire pressure monitoring system and engine compartment fire extinguisher provide peace of mind, whether operating a long-distance bus or tourist tram service.
Ideal for:
Starting at US$78,600 FOB Tianjin, including comprehensive warranty and customizable configurations. Optimize your fleet with the BJ6122 – the ultimate choice for tour coach operators and tourist bus services.
Upgrade your transportation solutions today with the BJ6122 Diesel Bus – where innovation meets reliability.
