Home > Products > Dump Truck > Auman GTL Heavy-Duty Truck 8×4 80T Box Dump Truck/slag truck/miner's truck For Peru
Market Price: from $51,800
Series: Auman GTL
Usage scenario: slag truck/miner's truck/bogie truck
Max Power: 430
Drive Type: 8X4
Wheelbase(mm): 1800+4700+1350
Engine/Battery: Foton Comins ISG12
Transmission: Fast 12JSDX240T(Q)Iron
Serial Number | 40 |
Business | Heavy-duty Truck (H1) |
Brand | Auman |
Function | Dump Truck |
Platform | GTL |
Tonnage / Boom Length | 80T |
Drive | 8×4 |
Engine | ISG12 |
Transmission | F-12MT |
Announcement Model | BJ3319DNPKJ-A3 |
Sales Country | Peru |
Covered Countries | Peru |
Status | Complete Vehicle |
Drive Form | 8×4 |
Wheelbase | 1800+4700+1350 |
Overall Dimensions of Vehicle (Chassis) | 12000×2495×3580 |
Inner Dimensions of Cargo Box | 9400×2300×900 |
GVW | 80000 |
GCW | / |
Body Width | 2490 |
Roof Height | Flat Roof |
Left/Right Hand Drive | Left Hand Drive |
Cab Status | / |
Number of Seats (Passenger Capacity) | 2 |
Fuel Type | Diesel |
Engine | ISGe5-430 |
Engine Manufacturer | Foton Cummins Engine |
Displacement | 11800 |
Emission | Euro Ⅴ |
Emission Route | SCR |
Power/Speed (Horsepower) kw/ps(r/min) | 430 |
Engine Torque
(Nm/rpm) |
2200/1000 |
Transmission Model | 12JSDX240T(Q)Iron |
Transmission Manufacturer | Fast |
Front Axle Load | 9T |
Middle/Rear Axle Load | 16T |
Drive Axle Ratio | 4.76 |
Brake Type | Air Brake |
Brake Form | Front Drum and Rear Drum |
Brake Control System | ABS |
Tire Model | 12.00R20 |
Number of Tires | 13 |
Steering Gear | AM105L-S |
Fuel Tank Capacity | 350L Aluminum Alloy |
Suspension Form | Leaf Spring |
Number of Leaf Spring Pieces | 14/13, 14 |
Frame Section/mm | 225/320×90×(8+7) |
Standard Air Conditioner | Manual Air Conditioner |
Standard Entertainment System (Including Radar) | MP3 + Radio + USB + No Radar |
Standard Body Combination (Seats, Doors and Windows, Rearview Mirrors) | Power Windows + Central Lock + Remote Door Lock + Five Locks Unified + Airbag Seat (Standard) + Manual Rearview Mirror |
Engine Optional | 431/0 |
Body Combination Optional | D52/D53 |
Transmission Optional | 370/0 |
Front Axle Optional | 09T/0 |
Middle and Rear Axle Optional | Q1 |
Tire Optional | Z8/XD/XC/Z7/N7/N6/ZL |
Fuel Tank Optional | L35/L60/L36 |
Air Conditioner Optional | K/0 |
Entertainment System (Including Radar) Optional | MSW/NSW |
Fifth Wheel | 0 |
Air Deflector | 0 |
Bumper Optional | XBT/0 |
Satellite Positioning Device | 0 |
Upper Mounting | 000/00D |
Fuel Injection System | Y/0 |
Battery Optional | 165/0 |
Stabilizer Bar Optional | H/0 |
Wheel Guard Optional | 0 |
Air Filter Type Optional | WS/0 |
Independent Heat Source Optional | 0 |
Additional Equipment | 0 |
When it comes to tackling the most demanding hauling tasks—whether in mining operations, construction sites, or industrial slag removal—you need a workhorse that combines raw power, unwavering durability, and smart engineering. Introducing the Auman GTL 80T dump truck, a masterpiece designed to excel as a miner's truck, slag truck, and a robust bogie truck, all rolled into one.
Built on the trusted GTL platform, this 8×4 bogie truck isn't just a vehicle—it's a solution for Peru's toughest industries. With a Gross Vehicle Weight (GVW) of 80,000 kg, it stands ready to carry massive loads, making it the perfect miner's truck for extracting and transporting ore, or a reliable slag truck for moving industrial waste with efficiency.
Under the hood, the Foton Cummins ISGe5-430 engine roars to life with 430 horsepower and a staggering 2200 Nm of torque, paired with a 12-speed Fast 12JSDX240T transmission. This powertrain ensures seamless acceleration even under full load, while the 4.76 drive axle ratio optimizes both power and fuel efficiency—critical for long hours in remote mining areas or busy construction zones.
Durability is non-negotiable. The Auman GTL 80T features a rugged frame with a cross section of 225/320×90×(8+7) mm, 9T front axles, and 16T middle/rear axles, all built to withstand constant punishment. Its 9400×2300×900 mm cargo box offers ample space for bulk materials, while the air brake system with ABS and 12.00R20 tires guarantee safe handling on uneven terrain—whether you're navigating a mine slope or a construction site.
Comfort isn't overlooked either. The平顶 (flat roof) cab comes with airbag seats, manual air conditioning, and an entertainment system with MP3, radio, and USB—small touches that make long shifts more bearable for drivers. With a 350L aluminum fuel tank, refueling stops are minimized, keeping your operations running smoothly.
Whether you need a miner's truck for heavy ore transport, a slag truck for industrial waste removal, or a versatile bogie truck for all-around heavy-duty work, the Auman GTL 80T delivers. Engineered for Peru's unique demands, it's more than a truck—it's a partner in productivity.
Ready to elevate your hauling capabilities? Choose the Auman GTL 80T—where power, durability, and efficiency meet.
