Home > Products > Special truck > Foton LOXA crane truck whole truck 8t Auman Planet chassis 5-section boom>
Market Price: from $53235 (NO include VAT)
Series: PLANET&LOXA
Usage scenario: /construction material transport/heavy lifting/equipment handling/infrastructure maintenance
Max Power: 240
Drive Type: 4X2
Wheelbase(mm): 3950 / 4500 / 5150
Engine/Battery: Yuchai Engine YCS04240-66
Transmission: FAST 8JS85E-C
| Category | Details |
|---|---|
| Approved Model | BJ5181JSQY6AKS-01 |
| Cab | MA5 Single Row Flat Roof |
| Suspension Type | Semi-floating coil spring |
| Engine | YCS04240-66 |
| Transmission | 8JS85E Iron |
| Wheelbase | 3950 / 4500 / 5150 mm |
| Frame | 300×80×(8+5) mm partial three-layer with wing plate |
| Leaf Spring | 10 / 10+8 |
| Front Axle | 5.5T |
| Rear Axle | 10T (435) speed ratio 5.143 |
| Tire | 10.00R20 18PR |
| Fuel Tank | 300L Aluminum Alloy |
| Overall Dimensions | 8245 / 9000 / 7390 × 2550 / 2500 × 3780 / 3850 / 3950 mm |
| Cargo Box Dimensions | 4500-6100 × 2450 / 2400 × 550 mm |
| Upper Structure Configuration | Foton Loxa Loxa805 / 8-ton 5-section boom crane, boom length 18.8 m, maximum lifting height 20.5 m. Double-stage front outriggers (7.8 m), double gear pump, high-position turntable seat, automatic hook retraction. |
| Other Configurations | Airbag seat + Power windows + Manual mirrors, MP3, Central locking, Standard steering wheel, Manual body flip, PTO switch, Power take-off, Manual air conditioning, Cruise control, Reverse buzzer, Remote throttle, Middle seat |
| Optional | Multifunction steering wheel, 7-inch MP5 + Reverse camera + Bluetooth + Navigation |
| Category | Details |
|---|---|
| Internal Identification Name | LOXA805 |
| Crane Model | S200X5 |
| Max. Lifting Capacity (kg) | 8000 |
| Max. Lifting Moment (t·m) | 220 |
| Max. Lifting Height (m) | 20.5 |
| Boom Length (m) | 5.4 |
| Full Extension Length of Boom (m) | 18.8 |
| Luffing Angle Range (°) | 0-75 |
| Outrigger Span (Full Extended) (m) | 6 |
| Boom Type | Single Cylinder 5-Section Boom |
| Boom Section | Octagonal |
| Hydraulic System Pressure (MPa) | 26 |
| System Flow (L/min) | 50+32 |
The Aumark BJ5181JSQY6AKS-01 8-ton truck-mounted crane is a versatile and powerful crane truck designed for efficient loading and unloading in construction, logistics and infrastructure projects. Equipped with the Foton Loxa Loxa805 8-ton 5-section boom crane (18.8 m boom length, 20.5 m maximum lifting height), double-stage front outriggers and double gear pump, this crane truck delivers strong lifting capacity and precise operation for heavy materials.
Powered by the reliable YCS04240-66 engine and 8-speed manual transmission, with 5.5T front axle and 10T rear axle, it offers excellent stability and mobility whether on job sites or during construction material transport. The spacious single-row flat-roof cab with airbag seat, power windows, cruise control and manual air conditioning keeps the operator comfortable during long working days of heavy lifting and equipment handling.
Ideal for urban construction sites, rural infrastructure projects, warehouse loading/unloading and roadside maintenance, this crane truck helps you complete jobs faster, reduce labor costs and increase daily productivity in construction material transport, heavy lifting, equipment handling and infrastructure maintenance. Choose this reliable truck-mounted crane to boost your operational efficiency and profitability across various lifting and transport tasks.
