video of Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual
Foton Auman  Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual

Foton Auman Euro II 22T 4×2 Fence Cargo Truck LHD Yuchai engine Manual

Market Price: from $24000 (NO include VAT)

Series: Foton Auman

Usage scenario: construction material transport,agricultural product hauling,heavy cargo hauling,market logistics,infrastructure support

Max Power: 240

Drive Type: 4X2

Wheelbase(mm): 4800

Engine/Battery: Yuchai YC6A240-33

Transmission: Fast Gear 8JS105TA manual

truck inspection
factory visiting

Brand

Auman

Tonnage Series

22T

Product Line

2200_4800

Vehicle Category

General Type

Vehicle Serial Number

Cab Type

Extended Cab

Steering Layout

LHD

Business Unit

/

Announcement Model

BJ1226VMPHG-1

Available Flatbed Announcement

/

Available Box Body Announcement

/

Available Stake Body Announcement

/

Project Name

Overseas Low Emission - Cameroon M4 Medium Truck 22T Platform 4800 Wheelbase YC6A240-33 Powertrain Project

Product Platform

M4

Development Type

Overseas Market

Project Grade

B3

Project Source

Notice on Launching Low-Emission Product Project for M4 Medium Truck 22T Platform for Overseas Markets

Business Line

Medium Truck

Motor Vehicle Classification

N3

Vehicle Emission Standard

Euro II

GVW (kg)

22T

Overview of Base Vehicle Features

2200 wide extended LHD cab, YC6A240-33 engine + 8JS105TA transmission + φ395 diaphragm spring clutch + 5750mm wheelbase + multi-leaf spring 10/10+8 + rear axle with final drive ratio 4.875 + 11R22.5 18PR tires, power take-off coordinate (795,0,10; rear end of engine cylinder block)

Modifications of New Model

Wheelbase adjusted from 5750mm to 4800mm (matched with 6200mm cargo box), other specifications consistent with base vehicle; 10R22.5 tire option cancelled as it fails to meet the load demand of 22T platform; newly applied special parts shall be equipped with anti-corrosion protection scheme

Overview of New Vehicle Features

2200 wide extended LHD cab, YC6A240-33 engine + 8JS105TA transmission + φ395 diaphragm spring clutch + 4800mm wheelbase + multi-leaf spring 10/10+8 + rear axle with final drive ratio 4.875 + 11R22.5 18PR tires, power take-off coordinate (795,0,10; rear end of engine cylinder block)

Basic Configuration Parameters

Engine - Manufacturer

Guangxi Yuchai Machinery Co., Ltd.

Engine - Model

YC6A240-33

Engine - Displacement (L)

Engine - Power (hp)

240

Engine - Torque (N.m)

Engine - Emission Standard

National III

Engine - Fuel Injection System

Engine - Voltage

24V

Engine - Cooling Fan

Conventional Silicone Oil Fan

Engine - Remarks

/

Aftertreatment System - Type

Aftertreatment System - Model

Aftertreatment System - Packaging Manufacturer

Aftertreatment System - Remarks

/

Clutch - Type

Single Dry Diaphragm Spring

Clutch - Size (mm)

φ430×φ240

Clutch Control

Hydraulic Control with Air Booster

Transmission - Model

8JS105TA

Transmission - Type

Manual (MT)

Front Axle - Type

Non-split I-beam

Front Axle - Rated Load (T)

5.5

Front Axle - Main Section Size (mm)

90×75×104

Front Axle - Drop Depth (mm)

92.3+37

Frame - Connection Type

Riveted Frame

Frame - Overall Width (mm)

940/865

Frame - Longeron Section (Front/Mid/Rear) mm

250

Steering System - Steering Gear Type

Recirculating Ball Type

Steering System - Steering Cylinder Bore (mm)

100

Front Suspension - Type

Non-independent Longitudinal Leaf Spring Suspension

Front Suspension - Leaf Spring Layers

10

Brake System - Front Brake Size (mm)

Drum Air Brake

Rear Axle - Model

153

Rear Axle - Rated Load (T)

10T

Rear Axle - Axle Housing Type

Stamped & Welded Integral Housing

Rear Axle - Housing Section (mm)

135×150×12

Rear Axle - Final Drive Ratio

4.875

Brake System - Rear Brake Size (mm)

Drum Air Brake

Brake System - Parking Brake

Spring Brake

Brake System - Auxiliary Brake

Exhaust Brake

Cargo Floor Height (mm)

1035

Rear Suspension - Type

Non-independent Longitudinal Leaf Spring Suspension

Rear Suspension - Leaf Spring Layers

10+8

Whole Vehicle Design Parameters

Wheelbase (mm)

4800

Track Width (Front/Rear) (mm)

2008/1860

Max Speed (km/h)

105

Body Form

Chassis / Flatbed / Box Body / Stake Body

Dimension (L×W×H) (mm) - Overall Vehicle Dimension

8255×2460×2820

Dimension (L×W×H) (mm) - Inner Cargo Box Dimension

/

Mass Parameters (kg) - Gross Vehicle Weight

22000

Mass Parameters (kg) - Rated Payload / Passenger Capacity

/2

Mass Parameters (kg) - Curb Weight

5440

Standard Main Configuration List

No Airbag / No PTO / Front & Rear Drum Lightweight Rear Axle / Hydraulic Cab Tilt / No Air Deflector / No ADAS / Without Cargo Box / Manual A/C / Tubeless Tire (Imperial) 11R22.5 / Manual Windows & Mirrors (Matched with 2450mm inner width cargo box) / No Tachograph / No Stabilizer Bar / MP3 Player / Without ABS / Power Steering / Knitted Spring Shock-absorbing Seat /

Optional Configuration List

Optional Axle

Front & rear drum brake, small ratio (automatic slack adjuster) / Front & rear drum brake, small ratio (automatic slack adjuster without ABS) / Front & rear drum brake, standard ratio (automatic slack adjuster) / Front & rear drum brake, standard ratio (automatic slack adjuster without ABS) / Front & rear drum brake standard ratio / Front & rear drum brake standard ratio (manual slack adjuster with ABS) / Front & rear drum brake small ratio / Front & rear drum brake small ratio (manual slack adjuster with ABS) /

Optional Brake Control System

ABS /

Optional Tires

Tubeless tire (Metric) 295/80R22.5 / Tubeless tire (Metric) 295/80R22.5 Giti Wear-resistant Tire / 295/80R22.5 front steer rear drive /

Optional Transmission

Flange PTO /

Optional Steering System

Optional Suspension System

No stabilizer bar + 260L fuel tank /

Optional Window & Mirror Control

Central lock + electric windows + electric mirrors + heated mirrors /

Optional Cab Tilt

Optional Seats

Knitted air suspension shock-absorbing seat / Knitted spring shock-absorbing seat + middle seat / Knitted air suspension shock-absorbing seat + middle seat /

Optional Air Conditioner

Electric A/C /

Optional Driving Recorder

Overseas Tachograph /

Optional Infotainment System

MP5 + multi-function steering wheel / MP5 + rear view camera /

Optional Auxiliary Driving Equipment

Reverse Radar / Air Horn /

Optional Passive Safety Parts

Daytime Running Light /

Optional Cargo Box

Optional Air Deflector

With air deflector / Air deflector + 450L fuel tank / Without air deflector + 450L fuel tank / Without air deflector + extra fuel tank / Air deflector + extra fuel tank /

The Oumark M4 22T medium-duty truck is a highly capable, reliable and cost-effective workhorse engineered for the demanding conditions of Cameroon and similar African markets. Powered by the robust Yuchai YC6A240-33 diesel engine delivering 240 PS and 900 Nm of torque, paired with the proven Fast 8-speed manual transmission and strong leaf spring suspension, this vehicle offers excellent power delivery, durability and fuel efficiency for heavy daily operations. The 4800 mm wheelbase is perfectly matched to a 6200 mm cargo box, providing optimal balance between maneuverability and load capacity while the half-row cab ensures practical driver comfort during long hours on the road.

With a GVW of 22 tons and a robust chassis featuring 5.5T front axle, 10T rear axle, 11R22.5 tires and reinforced frame, the Oumark M4 cargo truck delivers superior payload performance and stability across varied terrains. Its Euro II emission compliance meets regional requirements while the aluminum fuel tank and durable components reduce maintenance needs and operating costs. This cargo truck brings real value by enabling higher daily productivity, lower total cost of ownership and greater reliability for businesses engaged in construction material transport, agricultural product hauling, general freight and urban-rural distribution. Operators appreciate the easy-to-drive characteristics, strong climbing ability and comfortable cab that make long shifts less tiring during intensive construction material transport and agricultural product hauling routes.

The versatile Oumark M4 platform excels in heavy cargo hauling, market logistics and infrastructure support projects across Cameroon. Its powerful engine and transmission combination ensures confident performance when fully loaded, while the robust suspension and brakes provide safe handling on both paved roads and challenging rural paths. For companies focused on construction material transport, the truck handles sand, gravel, cement and steel with ease, completing more trips per day with less fuel consumption. In agricultural product hauling, it efficiently moves crops, fertilizers and livestock feed from farms to markets, helping preserve product quality and maximize profitability. The cargo truck also shines in general heavy cargo hauling and market logistics where its large cargo space and reliable powertrain reduce turnaround times and improve supply chain efficiency. Additional applications such as infrastructure support benefit from the vehicle's ability to carry tools, equipment and materials to remote sites without compromise.

Choosing the Oumark M4 22T cargo truck means investing in a vehicle that delivers consistent performance, lower downtime and higher return on investment. The anti-corrosion measures and quality components ensure long service life even in humid and dusty African conditions. Drivers enjoy the practical half-row cab, manual controls that are intuitive and the overall build quality that inspires confidence on every journey. Fleet operators gain competitive advantages through reduced fuel costs, simpler maintenance schedules and the flexibility to handle diverse loads in construction material transport, agricultural product hauling, heavy cargo hauling, market logistics and infrastructure support operations. The truck's balanced design, strong powertrain and proven platform make it an ideal partner for growing businesses seeking dependable transportation solutions that contribute directly to profitability and operational success across Cameroon and beyond.

From daily urban deliveries to long-haul regional routes, the Oumark M4 cargo truck consistently outperforms expectations. Its 105 km/h top speed allows efficient highway running while the strong low-end torque excels on steep inclines common in many African regions. The 200L aluminum alloy fuel tank supports extended range, minimizing refueling stops during busy schedules. Safety features including reliable brakes and stable suspension further enhance driver confidence and reduce accident risks during heavy cargo hauling and market logistics tasks. Over time, owners experience lower total ownership costs, higher utilization rates and improved customer satisfaction thanks to timely deliveries powered by this capable cargo truck. Whether your business focuses on construction material transport for building projects, agricultural product hauling for seasonal demands, general heavy cargo hauling, efficient market logistics or essential infrastructure support, the Oumark M4 22T platform provides the performance, reliability and value needed to thrive in competitive markets.
