Home > Products > Dump Truck > africa> Foton Auman DUMP TRUCK 6×4 400hp 70T GTL-E for Africa>
Market Price: from $54520
Series: GTL-E
Usage scenario: transporting and unloading bulk materials/Construction site truck/ mining operations truck
Max Power: 400
Drive Type: 6×4
Wheelbase(mm): 3825+1350
Engine/Battery: Foton Cummins ISG12
Transmission: SINOTRUK HW-12MT
| Serial number | 207 |
| business | Heavy truck (H1) |
| brand | Auman |
| Function | Dump Truck |
| platform | GTL-E |
| Tonnage/arm length | 70T |
| drive | 6×4 |
| engine | ISG12 |
| Gearbox | HW-12MT |
| Announcement Model | BJ3259DLPKB-1 |
| Sales Country | Strategic Customers |
| Covered countries | Angola/Republic of Congo/Democratic Republic of Congo/Guinea/Cameroon/Laos/Nigeria |
| state | Complete vehicle |
| Drive type | 6×4 |
| Wheelbase | 3825+1350 |
| Overall dimensions of vehicle (chassis) | 7500×2490×3400 |
| Cargo compartment dimensions | 5600×2300×1100 |
| GVW | 25000 |
| GCW | 70000 |
| Body width | 2490 |
| Top height | Flat Top |
| Left and right rudder | Left rudder |
| Cab status | / |
| Number of seats (passenger capacity) | 2 |
| Fuel Type | diesel fuel |
| engine | ISG 400 |
| Engine Manufacturer | Fukang engine |
| Displacement | 11800 |
| emission | No emissions |
| Emission route | / |
| Power/speed (horsepower) kw/ps (r/min) | 294/400/1900 |
| Engine torque
(Nm/rpm) |
2100/1000 |
| Gearbox Model | HW23712 Iron (Q) |
| Gearbox manufacturers | Sinotruk |
| Front axle load | 9T |
| Middle/rear axle load | 16T |
| Drive axle ratio | 4.76 |
| Brake type | Air brake |
| Braking form | Front drum and back drum |
| Brake control system | ABS |
| Tire model | 13R22.5 18PR Mixed/Drive |
| Tire quantity | 11 |
| Steering gear | AM105L-S |
| Fuel tank capacity | 350L Aluminum Alloy |
| Suspension type | Leaf Spring |
| Number of leaf springs | 10，14 |
| Frame section/mm | 225/320×90×(8+7) |
| Air conditioning standard | Automatic air conditioning |
| Entertainment system (including radar) standard | MP3+Radio+USB+No Radar |
| Body assembly (seats, doors, windows, rearview mirrors) standard | Electric doors and windows + central locking + airbag seat (standard) + manual rearview mirror |
| Engine options | 381 |
| Body combination options | D22 |
| Gearbox options | 166 |
| Front axle option | / |
| Optional middle and rear axle | Q1/Q2/Q3/Q4/QR/QS |
| Tire options | UC/U8/N5/Z8/VE3/ZD |
| Fuel tank option | L35 |
| Air conditioning optional | Q |
| Entertainment system (including radar) optional | MSW |
| Saddle | 0 |
| Air deflector | 0 |
| Bumper Optional | XBT |
| Satellite positioning device | 0/J |
| Tops | 00D |
| Fuel injection system | / |
| Battery Optional | 165 |
| Stabilizer bar option | / |
| Wheel guard optional | 0 |
| Air filter type selection | SX |
| Independent heat source option | 0 |
| Additional Equipment | 0 |
| Resource availability date | August 18, 2023 |
| Resource Classification | Special review resources |
| Development Entity | Auman Technology Center |
| Material status | B1 Large quantity |
| Resource Status | reserve |
Transporting and unloading bulk materials with a 70-ton capacity, the Auman Dump Truck is perfect for moving large quantities of sand, gravel, soil, and construction waste.
Equipped with a powerful ISG12 engine delivering 400 horsepower and 2100 Nm of torque, ensuring exceptional performance even under the most challenging conditions.
Robust 6×4 drive system with a 3825+1350mm wheelbase, providing stability and maneuverability on rough terrain.
Features a durable Construction site truck design with a 5600×2300×1100mm cargo compartment, ideal for carrying heavy loads.
Equipped with advanced safety features including ABS braking system and air conditioning for driver comfort.
The mining operations truck is designed with a 6×4 drive type, offering excellent traction and power distribution.
Comes with a spacious 350L aluminum alloy fuel tank and a high-capacity 13R22.5 18PR tire setup for enhanced durability.
